Hexagon's newly redesigned software offers porosity/inclusion analysis in a single solution
In version 2025.3 of its VG software, Hexagon has now incorporated the enhanced version of its powerful Porosity & Inclusion analysis (PIA) tool that won an iF Award earlier this year.
Many automotive, aerospace and other manufacturers who use CT-scan-data analysis for quality assurance are already frequent users of this tool. Now enhanced with AI, the PIA quickly pinpoints and identifies discrepancies -- such as pores and inclusions deep within metal, plastic or composite parts, components or material samples -- from early product development stages through final manufacturing.
"This is the first time our tool combines all previous methods into a single, powerful solution, from analysis to reporting," says Jan Gräser, Product Manager VG Product Line, Manufacturing Intelligence Division. "We've completely redesigned the user interface for this feature to make it easier for everyone -- from beginners to experts -- to employ the PIA to understand their results and conduct even the most complex analyses easily, accurately, and efficiently."
Key features in the Porosity & Inclusion Analysis:
Intuitive design: All important settings are immediately visible and summarized at a glance, while advanced options are clearly accessible on separate tabs.
Efficient workflow: Fewer clicks, more overview, maximum control. For the first time, all porosity/inclusion analysis procedures have been brought together in a single solution. This allows for direct access to the core functions and eliminates the need to switch between different dialogs, saving valuable time.
Easier navigation: The new preview in the analysis dialog combines all key information and makes navigation easier thanks to the interactive minimap that shows the user's current position in the analysis window.
Other features in Hexagon’s 2025.3 VG software release:
Multipart coordinate measurement. This feature simplifies the handling of complex projects by allowing users to view, analyze, and edit measurement plans for multiple parts in one central location.
Create and modify dimensions directly in the 3D view. With the "Dimensioning" dialog open, create and adjust dimensioning features by dragging and dropping the measurement lines directly in the 3D view, allowing for easy placement in the correct direction and optimal visibility.
Improved deformation field capabilities for optical scans. This significant enhancement is specifically designed for complex morphing of incomplete optical scans.
Enhanced mesh import/export now supports GLB/GLTF, AMF, and 3MF file formats. This makes it easier to exchange 3D surface data with other applications.
"Our goal with the redesigned Porosity & Inclusion Analysis feature, as well as others in version 2025.3, is to streamline the way our users work with our software, helping them make decisions about design and manufacturing parameters faster and more efficiently," says Dr. Daniela Handl, General Manager VG, Manufacturing Intelligence Division.
"These robust capabilities will improve workflows and elevate the non-destructive evaluation process for a wide variety of manufacturers who employ 3D CT scanning for quality assurance."
